Description

• SPECIFICATIONS
• ColorBlack and White
• Printing ModeDirect Thermal Printing
• Resolution8 dots/mm (203 DPI)
• Printing Speed90mm/s
• Paper Width57mm (±0.5mm)
• Paper Roll DiameterMax. 50mm
• Printing WidthMax. 48mm
• Default Line Space3.75mm
• TPH50km
• Interface TypeUSB (Optional USB+LAN)
• Character SizeANK font; Font A: 12*24 dots; Font B: 9*17 dots; Traditional and Simplified Chinese: 24*24 dots
• Auto CutterN/A
• Printing CommandCompatible with ESC/POS
• CPU StorageUSB: 128 KB USB & LAN: 256 KB
• Flash StorageUSB: 8 MB USB & LAN: 8 MB
• Power InputAC 110V/220V, 50Hz to 60Hz
• Working PowerDC 9V/2A
• Cash Drawer ControlDC 12V/1A
• QR Code PrintingSupports
• Barcode PrintingUPC-A, UPC-E, JAN13(EAN13), JAN8(EAN8), CODE 39, ITF, CODABAR, CODE 93, CODE 128
• Fonts LibraryGB18030, Alphanumeric
• Other FontsPC347 (Standard Europe), Katakana, PC850 (Multilingual), PC860 (Portuguese), PC863 (Canadian French), PC865 (Nordic), West Europe, Greek, Hebrew, East Europe, Iran, WPC1252, PC866 (Cyril lic#2), PC852 (Latin2), PC858, IranII, Latvian, Arabic, PT151 (1251)
• OSWindwos, Android, IOS
• OtherSupport Bluetooth
• GENERAL
• Product Dimensions (L*W*H)120*105*105 (mm)
• Net Weight470g
• Working ConditionsTemperature: 0°C to 45°C; Humidity: 10% to 80% (non-condensing)
• Storage Conditionsge Conditions Temperature: -10°C to 60°C; Humidity 10% to 90% (non-condensing)
• ColorBlack (Optional: Black and White)
• CertificateCE, FCC, RoHS
• STANDARD PACKAGE DETAILS
• Package Dimensions (L*W*H)165*155*137 (mm)
• Gross Weight680g
• Packing List1*Printer, 1*Power Adapter, 1*Power Cable, 1*USB Communication Cable, 1*User Manual, 1*Driver CD, 1*Paper Roll
